Road

NS1 RIVAL AXS

Starting at €4,799

SEE THE BIKES

NS1 FORCE AXS

Starting at €6,599

SEE THE BIKES

NS1 RED AXS

Starting at €9,999

SEE THE BIKES

NS1 ULTEGRA Di2

Starting at €6,599

SEE THE BIKES

NS1 DURA ACE Di2

Starting at €9,999

SEE THE BIKES

FORMULA FOR SPEED

FULL CARBON FRAME AND FORK

ALL NEW VENTUM RACE GEOMETRY

NEW AERO HEAD TUBE

10MM OFFSET VENTUM CARBON SEATPOST

UDH COMPATIBILITY

INTEGRATED CABLE ROUTING

T-47 BOTTOM BRACKET

TIRE CLEARANCE TO 700x35C

3 NEW COLORWAYS.

GEOMETRY & SIZING

FRAME SIZE	XS	S	M	M/L	L	XL
(A) STACK	493	515	541	565	590	615
(B) REACH	370	378	388	397	405	413
(C) HEAD TUBE LENGTH	90	110	133	158	185	211
(D) CHAINSTAY LENGTH	410	410	410	410	410	410
(E) FRONT CENTER	568	574	584	600	615	631
(F) WHEELBASE	968	974	984	1000	1015	1031
(G) BOTTOM BRACKET DROP	69	69	69	69	69	69
(H) SEAT TUBE ANGLE	73.5°	73.5°	73°	73°	73°	73°
(I) HEAD TUBE ANGLE	71°	72°	73°	73°	73°	73°
(J) TOP TUBE LENGTH	516	531	553	570	585	601
(K) SEAT TUBE LENGTH (PHYSICAL)	439	448	473	490	527	543
(L) STAND OVER HEIGHT	730	745	770	788	820	840
(M) TRAIL	70.9	64.5	58.1	58.1	58.1	58.1
(N) FORK LENGTH, FULL	373	373	373	373	373	373
(O) FORK OFFSET	45	45	45	45	45	45

72 Hours in Patagonia, Arizona

Ventum Tech Talks Playlist Underbiking Park City Mountain

Ventum NS1 Road Bike Playlist Go Further - Rob Martinez

True Grit - Ryan Standish

Unbound Gravel | A Tribute to The 9-5 Worker

SUPPORT

We Stand Behind Our Products

Ventum stands behind the quality of our bikes, engineering, and all of our products. Each item is meticulously designed in-house by our team of passionate riders. Our goal is to elevate your experience and to deliver products that can withstand all normal rugged wear and tear that comes with competing in a triathlon, running a crit series, or enjoying a long gravel road to nowhere.

If you are not satisfied with your order, please contact our customer support team.

Sizing

&nbsp

Ordering, Shipping, Warranty, & Returns

&nbsp

It can take up to 30 days to process a return or refund.

&nbsp

Bikes shipped outside of the continental US are handled by our regional partners. The assembly required upon final delivery can vary, but you should expect to install the wheels, seatpost, and the stem onto the steerer tube.

&nbsp

https://ventumracing.com/warranty/

Financing & Trade-Ups

&nbsp

Submit your bike directly to The Pro’s Closet, and share their offer with support@ventumracing.com. The trade-up value will be deducted from your order total. We’ll need to email you a custom invoice, so don’t order online before speaking with Ventum Support. The trade-up bike will need to be shipped to The Pro’s Closet within 2 weeks–we supply the shipping label.

&nbsp

Yes, we offer financing through Klarna for most customers in the USA.

&nbsp

Prices online are listed in USD, and Ventum does ship internationally for $299.

General Product Information

&nbsp

Ventum seldom publishes complete build weights as several factors can cause weight to vary. Please reach out to support@ventumracing.com with further questions pertaining to weight figures regarding bike builds.

&nbsp

Current Model GS1 - Tire clearance to 700x56c in the front and 700x50c in the rear.

Current Model NS1 - Tires measuring up to 35mm in width (700x35C)

Current Model Tempus - Tires measuring up to 30mm in width (700x30C)

Legacy GS1 (pre-2025) - Tires measuring up to 48mm in width (700x48C)*

Ventum One Disc - 28mm max (700x28C)

&nbsp

The NS1 and Tempus are typically equipped with 700x28C or 700x30C tires. The specific tire is subject to change depending on availability. Reach out to support@ventumracing.com for more information.

The GS1 will be equipped with tubeless gravel tires, typically on size 700x48C

&nbsp

Ventum does not offer custom paint options, but we do offer an array of color options for each bike type.
